Redone to minimize area.

"Jon Slaughter" schreef in bericht
et...
Redone to minimize area.



Hmm... nice picture. But what's its use? Guess I missed something.

petrus bitbyter

"petrus bitbyter" wrote in message
l.nl...

"Jon Slaughter" schreef in bericht
et...
Redone to minimize area.



Hmm... nice picture. But what's its use? Guess I missed something.


Its a digital level translator. Theres 8 discrete channels and 8 integrated.
The IC does it but isn't full duplex or direction independent like the
discrete ones which is why I had to put them in.

On 18/10/2007 Jon Slaughter wrote:


"petrus bitbyter" wrote in
message l.nl...

"Jon Slaughter" schreef in bericht
et...
Redone to minimize area.



Hmm... nice picture. But what's its use? Guess I missed something.


Its a digital level translator. Theres 8 discrete channels and 8
integrated. The IC does it but isn't full duplex or direction
independent like the discrete ones which is why I had to put them in.

And the schematic is where?

--
John B

"John B" wrote in message
t...
On 18/10/2007 Jon Slaughter wrote:


"petrus bitbyter" wrote in
message l.nl...

"Jon Slaughter" schreef in bericht
et...
Redone to minimize area.



Hmm... nice picture. But what's its use? Guess I missed something.


Its a digital level translator. Theres 8 discrete channels and 8
integrated. The IC does it but isn't full duplex or direction
independent like the discrete ones which is why I had to put them in.

And the schematic is where?


Huh... this is not for. It's not something special that I'm giving out or
anything. Just a simple project I did and I posted my results because I had
a discussion with some others about routing issues.

On Thu, 18 Oct 2007 15:54:14 GMT, "Jon Slaughter"
wrote:

Redone to minimize area.


Minor pickey: we wouldn't parallel the two surface-mount pins
(lower-left on the chip) like that. It would look too much like a
solder bridge. It's better to run the paralleling trace off to the
left, where it's more visible and makes inspection easier.

Of course, you already know that it's not a solder bridge!

John

"John Larkin" wrote in message
...
On Thu, 18 Oct 2007 15:54:14 GMT, "Jon Slaughter"
wrote:

Redone to minimize area.


Minor pickey: we wouldn't parallel the two surface-mount pins
(lower-left on the chip) like that. It would look too much like a
solder bridge. It's better to run the paralleling trace off to the
left, where it's more visible and makes inspection easier.

Of course, you already know that it's not a solder bridge!


Maybe, I thought about it because it sorta looks odd the way I did it. I was
either thinking to run them both to the source in parallel or sorta "hook"
one into the other(the hook looked ust as ugly). In this case it wasn't a
big deal so I just did the easiest thing

Although, maybe it could cause a slight issue with seating the leads? I
guess I'll find out when I solder them.

Still trying to figure out how to print it well. Ink jet on transparency
isnt' working to well. Its about 5 to 10% transparent and very irregular.
Probably fine for short exposure times but I'm trying to think about how to
fix that. (I don't remember having that issue before but maybe I wasn't
paying attention to it) Going to probably take it somewhere and get it
printed but finishing up a few other circuits that I'm doing first.

Thanks,
Jon

"Jon Slaughter" wrote in message
t...

"John Larkin" wrote in
message ...
On Thu, 18 Oct 2007 15:54:14 GMT, "Jon Slaughter"
wrote:

Redone to minimize area.


Minor pickey: we wouldn't parallel the two surface-mount pins
(lower-left on the chip) like that. It would look too much like a
solder bridge. It's better to run the paralleling trace off to the
left, where it's more visible and makes inspection easier.

Of course, you already know that it's not a solder bridge!


Maybe, I thought about it because it sorta looks odd the way I did it. I
was either thinking to run them both to the source in parallel or sorta
"hook" one into the other(the hook looked ust as ugly). In this case it
wasn't a big deal so I just did the easiest thing

Although, maybe it could cause a slight issue with seating the leads? I
guess I'll find out when I solder them.

Still trying to figure out how to print it well. Ink jet on transparency
isnt' working to well. Its about 5 to 10% transparent and very irregular.
Probably fine for short exposure times but I'm trying to think about how
to fix that. (I don't remember having that issue before but maybe I wasn't
paying attention to it) Going to probably take it somewhere and get it
printed but finishing up a few other circuits that I'm doing first.


Actually I'll probably change it because its quite ugly on both sides of the
pin.

On Fri, 19 Oct 2007 01:29:07 -0500, "Jon Slaughter"
wrote:


"Jon Slaughter" wrote in message
et...

"John Larkin" wrote in
message ...
On Thu, 18 Oct 2007 15:54:14 GMT, "Jon Slaughter"
wrote:

Redone to minimize area.


Minor pickey: we wouldn't parallel the two surface-mount pins
(lower-left on the chip) like that. It would look too much like a
solder bridge. It's better to run the paralleling trace off to the
left, where it's more visible and makes inspection easier.

Of course, you already know that it's not a solder bridge!


Maybe, I thought about it because it sorta looks odd the way I did it. I
was either thinking to run them both to the source in parallel or sorta
"hook" one into the other(the hook looked ust as ugly). In this case it
wasn't a big deal so I just did the easiest thing

Although, maybe it could cause a slight issue with seating the leads? I
guess I'll find out when I solder them.

Still trying to figure out how to print it well. Ink jet on transparency
isnt' working to well. Its about 5 to 10% transparent and very irregular.
Probably fine for short exposure times but I'm trying to think about how
to fix that. (I don't remember having that issue before but maybe I wasn't
paying attention to it) Going to probably take it somewhere and get it
printed but finishing up a few other circuits that I'm doing first.


Actually I'll probably change it because its quite ugly on both sides of the
pin.



We would hook/loop it outside the IC footprint, so the trace is
clearly visible, not to mention klugable.

We let our production people review our layouts for stuff like this:
ease of placement, inspection clearances, fiducials, mechanics, things
like that. So we can share the blame.

John

"John Larkin" wrote in message
...
On Fri, 19 Oct 2007 01:29:07 -0500, "Jon Slaughter"
wrote:


"Jon Slaughter" wrote in message
. net...

"John Larkin" wrote in
message ...
On Thu, 18 Oct 2007 15:54:14 GMT, "Jon Slaughter"
wrote:

Redone to minimize area.


Minor pickey: we wouldn't parallel the two surface-mount pins
(lower-left on the chip) like that. It would look too much like a
solder bridge. It's better to run the paralleling trace off to the
left, where it's more visible and makes inspection easier.

Of course, you already know that it's not a solder bridge!


Maybe, I thought about it because it sorta looks odd the way I did it. I
was either thinking to run them both to the source in parallel or sorta
"hook" one into the other(the hook looked ust as ugly). In this case it
wasn't a big deal so I just did the easiest thing

Although, maybe it could cause a slight issue with seating the leads? I
guess I'll find out when I solder them.

Still trying to figure out how to print it well. Ink jet on transparency
isnt' working to well. Its about 5 to 10% transparent and very
irregular.
Probably fine for short exposure times but I'm trying to think about how
to fix that. (I don't remember having that issue before but maybe I
wasn't
paying attention to it) Going to probably take it somewhere and get it
printed but finishing up a few other circuits that I'm doing first.


Actually I'll probably change it because its quite ugly on both sides of
the
pin.



We would hook/loop it outside the IC footprint, so the trace is
clearly visible, not to mention klugable.

We let our production people review our layouts for stuff like this:
ease of placement, inspection clearances, fiducials, mechanics, things
like that. So we can share the blame.


Hehe, well, unfortunately I have no one to blame but myself if it goes
wrong. I went ahead redid it.. I guess I can attach my final product. I'm
ready to etch but just waiting for the mask to dry a bit. Hopefully I don't
have any big trouble with it.

BTW, the other circuits are just for "conversion" so I can work with some
SMT IC's a bit easier. These circuits ended up being about 3-5 times larger
than I imagined ;/ I guess that is a normal side effect of single sided
stuff?

Thanks,
Jon
